Page 1 :
B Sc-II ClassNotes # 12, , Suresh DVNS, , Genetic code, A series of codons in part of a messenger RNA (mRNA) molecule., Each codon consists of three nucleotides, usually representing a single, amino acid. The nucleotides are abbreviated with the letters A, U, G, and C. This is mRNA, which uses U (uracil). DNA uses T (thymine), instead. This mRNA molecule will instruct a ribosome to synthesize a, protein according to this code., The genetic code is the set of rules by which information encoded in, genetic material (DNA or mRNA sequences) is translated into proteins, (amino acid sequences) by living cells., The code defines how sequences of three nucleotides, called codons,, specify which amino acid will be added next during protein synthesis., With some exceptions, a three-nucleotide codon in a nucleic acid, sequence specifies a single amino acid. Because the vast majority of, genes are encoded with exactly the same code (see the RNA codon, table), this particular code is often referred to as the canonical or, standard genetic code, or simply the genetic code, though in fact there, are many variant codes. For example, protein synthesis in human, mitochondria relies on a genetic code that differs from the standard, genetic code., Not all genetic information is stored using the genetic code. All organisms' DNA contains regulatory, sequences, intergenic segments, chromosomal structural areas, and other non-coding DNA that can, contribute greatly to phenotype. Those elements operate under sets of rules that are distinct from the, codon-to-amino acid paradigm underlying the genetic code., Discovery, The genetic code, After the structure of DNA was discovered by James Watson and, Francis Crick, who used the experimental evidence of Maurice Wilkins, and Rosalind Franklin (among others), serious efforts to understand the, nature of the encoding of proteins began. George Gamow postulated, that a three-letter code must be employed to encode the 20 standard, amino acids used by living cells to encode proteins. With four different, nucleotides, a code of 2 nucleotides could only code for a maximum of, 42 or 16 amino acids. A code of 3 nucleotides could code for a, maximum of 43 or 64 amino acids., The fact that codons consist of three DNA bases was first, demonstrated in the Crick, Brenner et al. experiment. The first, elucidation of a codon was done by Marshall Nirenberg and Heinrich J., Matthaei in 1961 at the National Institutes of Health. They used a cellfree system to translate a poly-uracil RNA sequence (i.e., UUUUU...), and discovered that the polypeptide that they had synthesized consisted of only the amino acid, phenylalanine. They thereby deduced that the codon UUU specified the amino acid phenylalanine. This, was followed by experiments in the laboratory of Severo Ochoa demonstrating that the poly-adenine RNA, sequence (AAAAA...) coded for the polypeptide, poly-lysine. and the poly-cytosine RNA sequence, (CCCCC...) coded for the polypeptide, poly-proline. Therefore the codon AAA specified the amino acid, lysine, and the codon CCC specified the amino acid proline. Using different copolymers most of the, remaining codons were then determined. Extending this work, Nirenberg and Philip Leder revealed the, triplet nature of the genetic code and allowed the codons of the standard genetic code to be deciphered. In
Page 2 :
B Sc-II ClassNotes # 12, , Suresh DVNS, , these experiments, various combinations of mRNA were passed through a filter which contained, ribosomes, the components of cells that translate RNA into protein. Unique triplets promoted the binding of, specific tRNAs to the ribosome. Leder and Nirenberg were able to determine the sequences of 54 out of 64, codons in their experiments., Subsequent work by Har Gobind Khorana identified the rest of the genetic code. Shortly thereafter, Robert, W. Holley determined the structure of transfer RNA (tRNA), the adapter molecule that facilitates the, process of translating RNA into protein. This work was based upon earlier studies by Severo Ochoa, who, received the Nobel prize in 1959 for his work on the enzymology of RNA synthesis. In 1968, Khorana,, Holley and Nirenberg received the Nobel Prize in Physiology or Medicine for their work., Transfer of information via the genetic code, The genome of an organism is inscribed in DNA, or in the case of some viruses, RNA. The portion of the, genome that codes for a protein or an RNA is called a gene. Those genes that code for proteins are, composed of tri-nucleotide units called codons, each coding for a single amino acid. Each nucleotide subunit consists of a phosphate, a deoxyribose sugar and one of the four nitrogenous nucleobases. The purine, bases adenine (A) and guanine (G) are larger and consist of two aromatic rings. The pyrimidine bases, cytosine (C) and thymine (T) are smaller and consist of only one aromatic ring. In the double-helix, configuration, two strands of DNA are joined to each other by hydrogen bonds in an arrangement known as, base pairing. These bonds almost always form between an adenine base on one strand and a thymine, base on the other strand, or between a cytosine base on one strand and a guanine base on the other. This, means that the number of A and T bases will be the same in a given double helix, as will the number of G, and C bases. In RNA, thymine (T) is replaced by uracil (U), and the deoxyribose is substituted by ribose.:127, Each protein-coding gene is transcribed into a molecule of the related polymer RNA. In prokaryotes, this, RNA functions as messenger RNA or mRNA; in eukaryotes, the transcript needs to be processed to, produce a mature mRNA. The mRNA is, in turn, translated on the ribosome into an amino acid chain or, polypeptide. Chp 12 The process of translation requires transfer RNAs specific for individual amino acids with, the amino acids covalently attached to them, guanosine triphosphate as an energy source, and a number of, translation factors. tRNAs have anticodons complementary to the codons in mRNA and can be "charged", covalently with amino acids at their 3' terminal CCA ends. Individual tRNAs are charged with specific amino, acids by enzymes known as aminoacyl tRNA synthetases, which have high specificity for both their cognate, amino acids and tRNAs. The high specificity of these enzymes is a major reason why the fidelity of protein, translation is maintained., There are 4³ = 64 different codon combinations possible with a triplet codon of three nucleotides; all 64, codons are assigned for either amino acids or stop signals during translation. If, for example, an RNA, sequence, UUUAAACCC is considered and the reading frame starts with the first U (by convention, 5' to, 3'), there are three codons, namely, UUU, AAA and CCC, each of which specifies one amino acid. This, RNA sequence will be translated into an amino acid sequence, three amino acids long. 21–539 A given amino, acid may be encoded by between one and six different codon sequences. A comparison may be made with, computer science, where the codon is similar to a word, which is the standard "chunk" for handling data, (like one amino acid of a protein), and a nucleotide is similar to a bit, in that it is the smallest unit., The standard genetic code is shown in the following tables. Table 1 shows what amino acid each of the 64, codons specifies. Table 2 shows what codons specify each of the 20 standard amino acids involved in, translation. These are called forward and reverse codon tables, respectively. For example, the codon AAU, represents the amino acid asparagine, and UGU and UGC represent cysteine (standard three-letter, designations, Asn and Cys, respectively).522, RNA codon table, , nonpolar polar basic acidic (stop codon)
Page 4 :
B Sc-II ClassNotes # 12, , Suresh DVNS, , Sequence reading frame, A codon is defined by the initial nucleotide from which translation starts. For example, the string, GGGAAACCC, if read from the first position, contains the codons GGG, AAA and CCC; and, if read from, the second position, it contains the codons GGA and AAC; if read starting from the third position, GAA and, ACC. Every sequence can thus be read in three reading frames, each of which will produce a different, amino acid sequence (in the given example, Gly-Lys-Pro, Gly-Asn, or Glu-Thr, respectively). With doublestranded DNA there are six possible reading frames, three in the forward orientation on one strand and, three reverse on the opposite strand. The actual frame in which a protein sequence is translated is defined, by a start codon, usually the first AUG codon in the mRNA sequence., Start/stop codons, Translation starts with a chain initiation codon (start codon). Unlike stop codons, the codon alone is not, sufficient to begin the process. Nearby sequences (such as the Shine-Dalgarno sequence in E. coli) and, initiation factors are also required to start translation. The most common start codon is AUG which is read, as methionine or, in bacteria, as formylmethionine. Alternative start codons (depending on the organism),, include "GUG" or "UUG"; these codons normally represent valine and leucine, respectively, but as a start, codon, they are translated as methionine or formylmethionine., The three stop codons have been given names: UAG is amber, UGA is opal (sometimes also called, umber), and UAA is ochre. "Amber" was named by discoverers Richard Epstein and Charles Steinberg, after their friend Harris Bernstein, whose last name means "amber" in German. The other two stop codons, were named "ochre" and "opal" in order to keep the "color names" theme. Stop codons are also called, "termination" or "nonsense" codons. They signal release of the nascent polypeptide from the ribosome, because there is no cognate tRNA that has anticodons complementary to these stop signals, and so a, release factor binds to the ribosome instead., Effect of mutations, Examples of notable mutations that can occur in humans., During the process of DNA replication, errors occasionally, occur in the polymerization of the second strand. These, errors, called mutations, can have an impact on the, phenotype of an organism, especially if they occur within, the protein coding sequence of a gene. Error rates are, usually very low—1 error in every 10–100 million bases—, due to the "proofreading" ability of DNA polymerases., Missense mutations and nonsense mutations are examples, of point mutations, which can cause genetic diseases such as sickle-cell disease and thalassemia, respectively. Clinically important missense mutations generally change the properties of the coded amino, acid residue between being basic, acidic polar or non-polar, whereas nonsense mutations result in a stop, codon., Mutations that disrupt the reading frame sequence by indels (insertions or deletions) of a non-multiple of 3, nucleotide bases are known as frameshift mutations. These mutations usually result in a completely, different translation from the original, and are also very likely to cause a stop codon to be read, which, truncates the creation of the protein. These mutations may impair the function of the resulting protein, and, are thus rare in in vivo protein-coding sequences. One reason inheritance of frameshift mutations is rare is, that if the protein being translated is essential for growth under the selective pressures the organism faces,, absence of a functional protein may cause death before the organism is viable. Frameshift mutations may, result in severe genetic diseases such as Tay-Sachs disease., Although most mutations that change protein sequences are harmful or neutral, some mutations have a, positive effect on an organism. These mutations may enable the mutant organism to withstand particular
Page 5 :
B Sc-II ClassNotes # 12, , Suresh DVNS, , environmental stresses better than wild-type organisms, or reproduce more quickly. In these cases a, mutation will tend to become more common in a population through natural selection. Viruses that use RNA, as their genetic material have rapid mutation rates, which can be an advantage since these viruses will, evolve constantly and rapidly, and thus evade the defensive responses of e.g. the human immune system., In large populations of asexually reproducing organisms, for example, E. coli, multiple beneficial mutations, may co-occur. This phenomenon is called clonal interference and causes competition among the mutations., Degeneracy, Degeneracy is the redundancy of the genetic code. The genetic code has redundancy but no ambiguity, (see the codon tables above for the full correlation). For example, although codons GAA and GAG both, specify glutamic acid (redundancy), neither of them specifies any other amino acid (no ambiguity). The, codons encoding one amino acid may differ in any of their three positions. For example the amino acid, glutamic acid is specified by GAA and GAG codons (difference in the third position), the amino acid leucine, is specified by UUA, UUG, CUU, CUC, CUA, CUG codons (difference in the first or third position), while the, amino acid serine is specified by UCA, UCG, UCC, UCU, AGU, AGC (difference in the first, second or third, position).A position of a codon is said to be a fourfold degenerate site if any nucleotide at this position, specifies the same amino acid. For example, the third position of the glycine codons (GGA, GGG, GGC,, GGU) is a fourfold degenerate site, because all nucleotide substitutions at this site are synonymous; i.e.,, they do not change the amino acid. Only the third positions of some codons may be fourfold, degenerate.:521–522 A position of a codon is said to be a twofold degenerate site if only two of four possible, nucleotides at this position specify the same amino acid. For example, the third position of the glutamic acid, codons (GAA, GAG) is a twofold degenerate site. In twofold degenerate sites, the equivalent nucleotides, are always either two purines (A/G) or two pyrimidines (C/U), so only transversional substitutions (purine to, pyrimidine or pyrimidine to purine) in twofold degenerate sites are nonsynonymous. A position of a codon is, said to be a non-degenerate site if any mutation at this position results in amino acid substitution. There is, only one threefold degenerate site where changing to three of the four nucleotides may have no effect on, the amino acid (depending on what it is changed to), while changing to the fourth possible nucleotide, always results in an amino acid substitution. This is the third position of an isoleucine codon: AUU, AUC, or, AUA all encode isoleucine, but AUG encodes methionine. In computation this position is often treated as a, twofold degenerate site., There are three amino acids encoded by six different codons: serine, leucine, and arginine. Only two amino, acids are specified by a single codon. One of these is the amino-acid methionine, specified by the codon, AUG, which also specifies the start of translation; the other is tryptophan, specified by the codon UGG. The, degeneracy of the genetic code is what accounts for the existence of synonymous mutations., Degeneracy results because there are more codons than encodable amino acids. For example, if there, were two bases per codon, then only 16 amino acids could be coded for (4²=16). Because at least 21, codes are required (20 amino acids plus stop), and the next largest number of bases is three, then 4³ gives, 64 possible codons, meaning that some degeneracy must exist., These properties of the genetic code make it more fault-tolerant for point mutations. For example, in theory,, fourfold degenerate codons can tolerate any point mutation at the third position, although codon usage bias, restricts this in practice in many organisms; twofold degenerate codons can tolerate one out of the three, possible point mutations at the third position. Since transition mutations (purine to purine or pyrimidine to, pyrimidine mutations) are more likely than transversion (purine to pyrimidine or vice-versa) mutations, the, equivalence of purines or that of pyrimidines at twofold degenerate, sites adds a further fault-tolerance., Grouping of codons by amino acid residue molar volume and, hydropathy., A practical consequence of redundancy is that some errors in the, genetic code only cause a silent mutation or an error that would not, affect the protein because the hydrophilicity or hydrophobicity is, maintained by equivalent substitution of amino acids; for example, a, codon of NUN (where N = any nucleotide) tends to code for
Page 6 :
B Sc-II ClassNotes # 12, , Suresh DVNS, , hydrophobic amino acids. NCN yields amino acid residues that are small in size and moderate in, hydropathy; NAN encodes average size hydrophilic residues. These tendencies may result from the shared, ancestry of the aminoacyl tRNA synthetases related to these codons., Despite the redundancy of the genetic code, single point mutations can still cause dysfunctional proteins., For example, a mutated hemoglobin gene causes sickle-cell disease. In the mutant hemoglobin a, hydrophilic glutamate (Glu) is substituted by the hydrophobic valine (Val), that is, GAA or GAG becomes, GUA or GUG. The substitution of glutamate by valine reduces the solubility of β-globin which causes, hemoglobin to form linear polymers linked by the hydrophobic interaction between the valine groups,, causing sickle-cell deformation of erythrocytes. Sickle-cell disease is generally not caused by a de novo, mutation. Rather it is selected for in geographic regions where malaria is common (in a way similar to, thalassemia), as heterozygous people have some resistance to the malarial Plasmodium parasite, (heterozygote advantage)., These variable codes for amino acids are allowed because of modified bases in the first base of the, anticodon of the tRNA, and the base-pair formed is called a wobble base pair. The modified bases include, inosine and the Non-Watson-Crick U-G basepair., Variations to the standard genetic code, While slight variations on the standard code had been predicted earlier, none were discovered until 1979,, when researchers studying human mitochondrial genes discovered they used an alternative code. Many, slight variants have been discovered since then,] including various alternative mitochondrial codes,33] and, small variants such as translation of the codon UGA as tryptophan in the species Mycoplasma and, translation of CUG as a serine rather than a leucine in the genus Candida. In bacteria and archaea, GUG, and UUG are common start codons, but in rare cases, certain proteins may use alternative start codons not, normally used by that species., In certain proteins, non-standard amino acids are substituted for standard stop codons, depending on, associated signal sequences in the messenger RNA. For example, UGA can code for selenocysteine, and, UAG can code for pyrrolysine. Selenocysteine is now viewed as the 21st amino acid, and pyrrolysine is, viewed as the 22nd., Despite these differences, all known naturally-occurring codes are very similar to each other, and the, coding mechanism is the same for all organisms: three-base codons, tRNA, ribosomes, reading the code in, the same direction and translating the code three letters at a time into sequences of amino acids., Expanded genetic code, Since 2001, 40 non-natural amino acids have been added into protein by creating a unique codon, (recoding) and a corresponding transfer-RNA:aminoacyl – tRNA-synthetase pair to encode it with diverse, physicochemical and biological properties in order to be used as a tool to exploring protein structure and, function or to create novel or enhanced proteins., H. Murakami and M. Sisido have extended some codons to have four and five bases. Steven A. Benner, constructed a functional 65th (in vivo) codon., Origin, Despite the minor variations that exist, the genetic code used by all known forms of life is nearly universal., However, there are a huge number of possible genetic codes. If amino acids are randomly associated with, triplet codons, there will be 1.5 x 1084 possible genetic codes., Phylogenetic analysis of transfer RNA suggests that tRNA molecules evolved before the present set of, aminoacyl-tRNA synthetases.
Page 7 :
B Sc-II ClassNotes # 12, , Suresh DVNS, , Theoretically, the genetic code could be completely random (a "frozen accident"), completely non-random, (optimal) or a combination of random and nonrandom. There are enough data to refute the first possibility.], For a start, a quick view on the table of the genetic code shows a clustering of amino acid assignments., Furthermore, amino acids that share the same biosynthetic pathway tend to have the same first base in, their codons, and amino acids with similar physical properties tend to have similar codons., There are four themes running through the many theories about the evolution of the genetic code (and, hence the origin of these patterns):, , , , , , , , , Chemical principles govern specific RNA interaction with amino acids. Experiments with aptamers, showed that some amino acids have a selective chemical affinity for the base triplets that code for, them. Recent experiments show that of the 8 amino acids tested, 6 show some RNA triplet-amino, acid association. This has been called the stereochemical code. The stereochemical code could, have created an ancient core of assignments. The current complex translation mechanism involving, tRNA and associated enzymes may be a later development, and maybe protein sequences were, directly templated on base sequences., Biosynthetic expansion. The standard modern genetic code grew from a simpler earlier code, through a process of "biosynthetic expansion". Here the idea is that primordial life "discovered" new, amino acids (for example, as by-products of metabolism) and later incorporated some of these into, the machinery of genetic coding. Although much circumstantial evidence has been found to suggest, that fewer different amino acids were used in the past than today, precise and detailed hypotheses, about which amino acids entered the code in what order have proved far more controversial., Natural selection has led to codon assignments of the genetic code that minimize the effects of, mutations. A recent hypothesis suggests that the triplet code was derived from codes that used, longer than triplet codons (such as quadruplet codons). Longer than triplet decoding would have, higher degree of codon redundancy and would be more error resistant than the triplet decoding., This feature could allow accurate decoding in the absence of highly complex translational machinery, such as the ribosome and prior to the time when cells began making ribosomes., Information channels: Information-theoretic approaches see the genetic code as an error-prone, information channel. The inherent noise (that is, errors) in the channel poses the organism with a, fundamental question: how to construct a genetic code that can withstand the impact of noise while, accurately and efficiently translating information? These “rate-distortion” models suggest that the, genetic code originated as a result of the interplay of the three conflicting evolutionary forces: the, needs for diverse amino-acids, for error-tolerance and for minimal cost of resources. The code, emerges at a coding transition when the mapping of codons to amino-acids becomes nonrandom., The emergence of the code is governed by the topology defined by the probable errors and is, related to the map coloring problem.
