Page 2 :
ADVANCED SURVEYING (22301) V.A.P.M. ALMALA, , CLASS TEST-01, , PLANE TABLE SURVEYING MCQ (Multiple Choice Questions), , , , Test Pattern — DATE - 14/10/2021, , No. of Questions — 20 Que., TIME —- 09.30AM TO 10.00AM, Marks for each Question — 01 Mark, , , , , , , , Total Marks — 20 Marks, , , , , , ALL THE BEST, , , , All questions are Compulsory... ..., , Que. No. 01, Instrument is used to sight to an object., 1) Compass, 2) U—Frame, 3) Alidade, , 4) Plumbing fork, , Que. No. 02, , How many methods of plane table surveying are there?, , 4, , HALNURE K.M.
Page 3 :
ADVANCED SURVEYING (22301) V.A.P.M. ALMALA, , Que. No. 03, , Plane table (PT) surveying is a method., , 1) Graphical, 2) Linear, 3) Circular, , 4) Angular, , Que. No. 04, , Plane table is made of:, 1) Metal, 2) Rubber, 3) Wood, , 4) Plastic, , Que. No. 05, , Which of the below is used for levelling a plane table?, 1) Plumb bob, 2) Spirit level, 3) Compass, , 4) U-frame, , HALNURE K.M.
Page 4 :
ADVANCED SURVEYING (22301), , Que. No. 06, , Which of the below is not an advantage of PT survey?, 1) Used for accurate works, 2) Less costly, 3) Field book is not required, , 4) Rapid method, , Que. No. 07, , How many ways are there to orient a plane table?, 1) 1, 2) 3, 3) 2, , Que. No. 08, , Plane table surveying uses the methodology of;, , 1) Triangulation, 2) Contouring, 3) Ranging, , 4) Traversing, , HALNURE K.M., , V.A.P.M. ALMALA
Page 5 :
ADVANCED SURVEYING (22301) V.A.P.M. ALMALA, , Que. No. 09, , A plumbing fork is used to the plane table., , 1) Focus, 2) Centre, 3) Orient, , 4) Level, , Que. No. 10, , In the method of an intersection, only one linear measurement is made, , 1) True, 2) False, , Que. No, 11, , In which method there is only one station point is used for PT survey, 1) Traversing method, 2) Radiation method, 3) Both 1 &2, , 4) Intersection method, , HALNURE K.M.
